Balboa 54003 DIGDUPR1x Circuit Board

Description

Balboa 54003 DIGDUPR1x Circuit Board

The Replacement Balboa Circuit Board, Duplex Digital. OEM part number 54003.SpaGuts P/N: 10-175-4003

At the core of Balboa Water Group, is a fundamental commitment to the leisure water industry to provide a simple, comprehensive, single source solution to products that range and include the highest quality products in electronic control systems, jets, pumps, white goods and accessories.

Balboa 54003 DIGDUPR1x Circuit Board Features:

• This circuit board is compatible with the 30337 Balboa Sensor Assembly, 30274-1 Transformer, and any Balboa Lite Duplex or Duplex Digital Topside Panels with the correct button configurations.
• Tip: The “(x)” shown above is shorthand for a range of last letters on DIGDUPR1 chip numbers this circuit board can replace.
• This new OEM circuit board is for replacing Balboa 54003 circuit boards having a DIGDUPR1(x) chip number.
• Circuit Board Dimension (Approx): 6.625″ x 6.0625″.
• Pump 1 circuit, two speed, 110/220V, 12A Max
• Blower circuit, one speed, 110/220V, 10A Max
• Ozone circuit, 110/220V, 1A Max
• Light circuit, 12V, 12W
